15
13. In
sert the valve stem into the knob and push knob into place.
14. The igniter battery is not factory installed. A “AA” size alkaline
battery is located in the accessory box on the grill grate.
Install battery at this time following the instructions in
“Replacing the Igniter Battery” section.
At
tach Left Side Shelf
1. Unpack left side shelf.
2. Open grill li
d.
3. Remove 3 screws from the side of the side shelf.
4. Remove 2 screws on grill side panel and 1 screw
on grill control panel.
5. Attach the top of the side shelf to the grill (B) by inserting the
2 screws removed in Step 3 into the side shelf from inside the
grill hood and tighten. See illustration in Step 7.
6. Attach the bottom of the side shelf to the side panel (A)
of the grill by inserting the 2 screws removed from the grill
side panel in Step 4. Tighten these screws.
See illustration in Step 7.
7. Attach the side shelf to the control panel (C) by inserting the
screw removed from the grill control panel in Step 4. Tighten
the screw.
A.
Side shelf screws
A. Grill side panel screws
B. Grill control panel screw
