11
Part
Number
Part(description)
Warranty
Coverage
Quantity
Part
Number
Part(description)
Warranty
Coverage
Quantity
1 Main lid 3 1 32 Door 1
1
2 Main lid screw 3 2 33 Door handle 1
1
3 Temperature gauge housing 1 1 34 Door handle seat 1
2
4 Temperature gauge 1 1 35 Door hinge 1
2
5 Main lid handle seat, left 1 1 36 Stationary caster 1
2
6 Main lid handle seat ,right 1 1 37 Lighting rod 1
1
7 Main lid handle tube 1 1 38 Left panel 3
1
8 Side shelf, left 1 1 39 Cart frame, front 1
1
9 Towel rack 1 2 40 Lighting rod cover 1
1
10 Side shelf supporting bracket
A
1 2 41 Regulator for LP unit 1
1
11 Side shelf trim panel, left 1 1 42 Logo 1
1
12 Side shelf supporting bracket
B
1 2 43 Control knob 1
2
13 Main lid bracket, left 1 1 44 Bezel 1
2
14 Warming rack 3 1 45 Control panel 3
1
15 Cooking grid 3 2 46 Electric igniter module 1
1
16 Flame tamer 3 2 47 Igniter junction wire 1
1
17 Main burner igniter wire A 1 1 48 Front baffle 1
1
18 Main burner 5 2 49 Main manifold 1
1
19 Main burner igniter wire B 1 1 50 Main gas valve 3
2
20 Main lid bracket, right 1 1 Preassembly hardware
21 Main burner bowl assembly 1 1 Manual
22 Side shelf trim panel, right 1 1
NG Package list*
23 Side shelf, right 3 1
Part
Number
Description Quantity
24 Rear panel 3 1 51 NG Regulator
assembly for NG unit
(sold separately)
1
25 Tank tray bolt 1 1 52 NG Gas Hose with
Quick Connector
assembly for NG unit
(sold Separately)
1
26 Side panel, right 3 1 53 6mm Nut Driver
(sold separately)
1
27 Swivel caster with brake 1 1 54 Hex Wrench
(sold separately)
1
28 Door hinge bracket 1 2 55 6mm Wrench
(sold separately)
1
29 Swivel caster 1 1 56 Truss Head Screw with
Lock
(sold separately)
2
30 Bottom panel 1 1 57 Flat Washer
(sold separately)
2
31 Grease box 3 1
*Natural gas conversion kit sold separately
