KitchenAid KBFC42FT - Page 12

13
Allow a minimum of 4¹⁄₂" (11.4 cm) of space between the side of the refrigerator and a corner wall. More clearance may be needed if
thicker custom panels or custom handles are used. Do not overlook baseboards.
1
/4" (6.35 mm)
3
/4" (1.9 cm)
1" (2.5 cm)
1
/2" (1.3 cm)
3
/4"
1"
1
1
/4"
1
1
/2"
1
/2"
Refrigerator
Side Trim
Door Backer Panel Overlay Panel
Hinge
Door Swing 90˚
Actual Size
Refrigerator to
Cabinetry Clearance
(1.9 cm)
(2.5 cm)
(3.8 cm)
(1.3 cm)
(3.2 cm)
Spacer Panel
Cabinetry
1
/2"
3
/4"
1"
(1.3 cm)
(1.9 cm)
(2.5 cm)
90˚ Door
Stop Position
