3
CABINET AND BREAKER TRIM PARTS
For Models: KBLC36FKB01, KBLC36FKS01
(Black) (Stainless Steel)
8198079
Illus. Part
No. No. DESCRIPTION
1 Cabinet, Trim
Right Side
2215919B Black
2215919S Stainless Steel
3 1163283 Screw
4 2254724 Cabinet, Trim
(Bottom)
5 486194 Screw
6 2003645 Cabinet, Trim Top
7 Breaker Trim
(Not Serviced)
8 2005782 Cover, Hinge
9 2005925 Seal−Trim,Side
10 Cabinet Trim,
Left Side
2215936B Black
2215936S Stainless Steel
11 489464 Screw, 8−18 x 1/2
