KitchenAid KHMC107E - Page 66

66
C aring for Your Microwave-Convection Hood Combination
3. We recommend replacing bulb(s) with
candelabra-base 30-watt bulb(s) available
from your authorized KitchenAid servicer
(Part No. 4158432).
wWARNING
Electrical Shock Hazard
Disconnect power before removing
vent cover.
Replace all panels before operating.
Failure to do so can result in death or
electrical shock.
3. Tip the cover forward, then lift out to
remove.
4. Remove bulb holder mounting screw.
The oven light
1. Turn off power at the main power supply.
2. Remove the vent cover mounting screws.
5. Lift up the bulb holder.
6. We recommend replacing the bulb with a
candelabra-base 30-watt bulb available
from your authorized KitchenAid servicer
(Part No. 4158432).
7. Replace the bulb holder and mounting
screw.
8. Slide the top of the vent cover into place.
Push the bottom until it snaps into place.
Replace the mounting screws. Turn the
power back on at the main power supply.
4359334 8/28/98, 12:05 PM66
