65
Replacing the cooktop and oven lights
wWARNING
Fire Hazard
Use only candelabra-base bulbs,
30-watt maximum.
Turn off power at main power
supply before replacing the light bulb.
Failure to follow the above could
result in fire or electrical shock.
C aring for Your Microwave-Convection Hood Combination
5. Slide the bottom of the vent cover into
place. Push the top until it snaps into
place. Replace the mounting screws.
After replacing filters:
• Turn the power back on at the main power
supply.
NOTE: Do not operate the hood without the
grease filters in place.
The cooktop light
1. Turn off power at the main power supply.
3. Lift the back of the charcoal filter. Slide
the filter straight out.
4. Slide a new charcoal filter into place. The
filter should rest at the angle shown.
2. Remove the bulb cover mounting screws.
continued on next page
4359334 8/28/98, 12:05 PM65
