KitchenAid KMMF330PSS - Page 16

16
3. Remove 2 blower screws attaching blower motor to the
microwave oven, and set aside.
A
A. Blower screws
4. Disconnect the blower motor wire from the connector.
A
B
A. Blower motor wire
B. Connector
5. Lift blower motor out of microwave oven, and set aside.
A
A. Blower motor
6. Using diagonal wire cutting pliers, gently snip out the
rectangular damper vent covers at the perforations.
B
A
A. Diagonal wire cutting pliers
B. Rectangular damper vent cover
7. Hold the blower motor wire, put the wire through the blower
motor bridge.
A
B
A. Blower motor bridge
B. Blower motor wire
8. Lower blower motor back into the microwave oven. Exhaust
ports face the back of the microwave oven.
A
A. Exhaust Port
9. Reconnect the blower motor wire into the connector.
A
B
A. Blower motor wire
B. Connector
