12
Cutout Height is Between 51³⁄₁₆" and 52³⁄₁₆" (130.0 cm and
132.6 cm)
1. Using 2 or more people, place the oven on its back on a
covered surface.
2. Install a foot on the left rear spacer using a #8-18 x ³⁄₈" screw.
NOTE: Position the foot so the short side of the foot is facing
toward the top of the oven.
3. In the same manner, install a foot on the right rear of the oven.
4. Install a front foot on the left front using a #8-18 x ³⁄₈" screw.
NOTE: Position the foot so the long side of the foot is facing
toward the top of the oven.
5. In the same manner, install a font foot on the right front of the
oven.
6. Using 2 or more people, place the oven in its upright position.
7. Go to the “Make Electrical Connection” section.
A. Spacer
B. Foot
C. #8-18 x
³⁄₈
" screw
A. Front foot
B. #8-18 x
³⁄₈
" screw
C. Spacer
