KitchenAid KODE500ESS Technical Education

iv
n
Built-In Single and Double Wall Ovens
PRODUCT SPECIFICATIONS & WARRANTY INFORMATION SOURCES (inside back cover)
SECTION 5 — WIRING DIAGRAMS
SINGLE OVEN - NON-CONVECTION ...........................................................................5-2
SINGLE OVEN - CONVECTION ....................................................................................5-3
DOUBLE OVEN - NON CONVECTION ..........................................................................
DOUBLE OVEN - SINGLE CONVECTION ......................................................................5-5
DOUBLE OVEN - DOUBLE CONVECTION ....................................................................
 .......................................................................................
TABLE OF CONTENTS

KitchenAid KODE500ESS Specifications

General

Type	Double Oven
Fuel Type	Electric
Convection	Yes
Self-Cleaning	Yes
Control Type	Touchscreen
Color	Stainless Steel
Voltage	240 V
Brand	KitchenAid
Model	KODE500ESS
Installation Type	Built-In
Number of Ovens	2
Upper Oven Capacity	5.0 cu. ft.
Lower Oven Capacity	5.0 cu. ft.
Amperage	40 A
Warranty	1 Year Limited
Total Capacity	10.0 cu. ft.
