3
Product Dimensions
Cutout Dimensions
22-3/4" (62.6 cm)
max.
recessed depth
A
10-1/4"
(26 po)
overall
height
B
Overall Recessed
Oven Size Width Width
27" 26-3/4" 25-1/4"
(68.6 cm) (67.9 cm) (64.1 cm)
30" 29-3/4" 28-1/4"
(76.2 cm) (75.6 cm) (71.8 cm)
BA
Warming
oven front
22-3/4"
(57.8 cm)
recessed
oven depth
24" (61 cm)
min. cutout
depth
Support surface must
be solid, level, and
flush with bottom of
cabinet cutout.
3 ft. (91.4 cm) long power
supply cord located on
the back, upper right
hand side of oven.
Single oven
cutout
Warming
oven cutouts
120-volt
grounded outlet
(or located in
adjacent cabinet)
Toe kick
cutout width
A
min. cabinet width
B
Oven Size
27" 25-1/2" 27"
(68.6 cm) 64.8 cm) (68.6 cm)
30" 28-1/2" 30"
(76.2 cm) (72.4 cm) (76.2 cm)
BA
Support
surface
2-1/2" (6.4 cm) min.
2-1/2" (6.4 cm) min.
4" (10.2 cm)
9-1/8" (23.2 cm)
9-1/8" (23.2 cm)
Recommended 4-1/4" (10.8 cm)
Minimum 1" (2.5 cm)
Warming oven can be installed as a
single or double installation or
installed under a single oven.Two
warming ovens under a single oven
are shown.
9" (22.9 cm)
recessed height
