Kitz Y Series User Manual

DocumentNo.:KE-0015-00                                        Sheet:7/37

Ⅰ ConstructionandDesignFeatures

ProductCode ServiceConditions Max. Permissible
Working  Pressure
10FDY
10FDYK
SteadyFlowat120℃ andlower 
PulsatingFlow,Steam,Oil*1,GasorAirat220℃ andlower
（For2”andsmaller,Maximumtemperatureshallbelimited
to200℃.）
1.37MPa
0.98MPa
10FDYBF

SteadyFlowat120℃ andlower 
PulsatingFlow,Steam,Oil*1,GasorAirat220℃ andlower
PulsatingFlow,Steam,Oil*1,GasorAirat300℃ andlower
（For 11/2” and smaller, Maximum temperature shall be
limitedto200℃.）
1.37MPa
1.18MPa
0.98MPa
10FDYBFK

SteadyFlowat120℃ andlower 
PulsatingFlow,Steam,Oil*1,GasorAirat220℃ andlower
PulsatingFlow,Steam,Oil*1,GasorAirat260℃ andlower
（For 11/2” and smaller, Maximum temperature shall be
limitedto200℃.）
1.37MPa
1.18MPa
1.07MPa
10UYA
10UYAM
SteadyFlowat120℃ andlower 
Steamat180℃ andlower 
1.37MPa
1.18MPa
UYB
UYBM
SteadyFlowat120℃ andlower 
PulsatingFlow,Steam,Oil*1,GasorAirat220℃ andlower

1.37MPa
0.98MPa
10SCY

SteadyFlowat120℃ andlower 
PulsatingFlow,Steam,Oil*1,GasorAirat220℃ andlower
PulsatingFlow,Steam,Oil*1,GasorAirat300℃ andlower
1.37MPa
1.18MPa
0.98ＭＰａ
VY Water, Chlorine, Bromine or other chemical fluids at 50℃
andlower.
0.98MPa
VYS Waterat50℃ andlower. 0.98MPa
125FCY Water,Oil*1orGasat120℃ andlower 
Saturatedsteam
1.37MPa
0.86MPa
16FDY
16FDYK
SteadyFlowat120℃ andlower 
PulsatingFlow,Steam,Oil*1,GasorAirat200℃ andlower
2.16MPa
1.96MPa
16FDYB SteadyFlowat120℃ andlower 
PulsatingFlow,Steam,Oil*1,GasorAirat220℃ andlower
PulsatingFlow,Steam,Oil*1,GasorAirat300℃ andlower
PulsatingFlow,Steam,Oil*1,GasorAirat350℃ andlower
（For 11/2” and smaller, Maximum temperature shall be
limitedto200℃.）
2.16MPa
1.96MPa
1.77MPa
1.57MPa
16FDYBK SteadyFlowat120℃ andlower 
PulsatingFlow,Steam,Oil*1,GasorAirat220℃ andlower
PulsatingFlow,Steam,Oil*1,GasorAirat260℃ andlower
（For 11/2” and smaller, Maximum temperature shall be
limitedto200℃.）
2.16MPa
1.96MPa
1.86MPa
20FDY
20FDYB
SteadyFlowat120℃ andlower 
PulsatingFlow,Steam,Oil*1,GasorAirat220℃ andlower
PulsatingFlow,Steam,Oil*1,GasorAirat300℃ andlower
PulsatingFlow,Steam,Oil*1,GasorAirat350℃ andlower
2.75MPa
2.45MPa
2.26MPa
1.96MPa
