Kitz Y Series User Manual

DocumentNo.:KE-0015-00                                        Sheet:2/37
Ⅰ ConstructionandDesignFeatures

1. FlangedYStrainer

1.1 ThetypicalYstrainerdesignisasillustratedbelow.

1.2 TheYstrainerisdesignedtoremoveforeignobjectsbythescreenequippedinsidethe
strainer.Itsflowdirectionandinstallationorientationaredeterminedbyitsstructure.



Thisillustrationrepresentsatypicalconstruction.
Body
Screen
Cap
Plug
Gusket
Flange
