Kitz Y Series User Manual

DocumentNo.:KE-0015-00                                        Sheet:3/37
Ⅰ ConstructionandDesignFeatures
2. ThreadedYStrainer

2.1 ThetypicalYstrainerdesignisasillustratedbelow.

2.2 TheYstrainerisdesignedtoremoveforeignobjectsbythescreenequippedinsidethe
strainer.Itsflowdirectionandinstallationorientationaredeterminedbyitsstructure.




Thisillustrationrepresentsatypicalconstruction.
Body
Screen
Gasket
Cap
Plug
