Kitz Y Series User Manual

DocumentNo.:KE-0015-00                                        Sheet:4/37
Ⅰ ConstructionandDesignFeatures

1. UStrainer

1.1 ThetypicalUstrainerdesignisasillustratedbelow.

1.2 TheUstrainerisdesignedtoremoveforeignobjectsbythescreenequippedinsidethe
strainer.Itsflowdirectionandinstallationorientationaredeterminedbyitsstructure.




Thisillustrationrepresentsatypicalconstruction.


Body
Screen
Gasket
Cap
Plug
Flange
