Sauna
PAGE 9
5070136/05.09
6. Individual settings
Unit/button: Description:
A Light switch
B 0/I button
C Operation LED
D Rotary knob temperature
6.1. Bathing temperature
Change Sauna bathing temperature with temperature rotary knob D.
The standard bathing temperature is 85 °C - 95 °C.
The center position of the temperature rotary knob corresponds to approx. 80 °C.
The temperature sensor is mounted in the warm air stream above the sauna heater.
An unavoidable temperature difference exists between the temperature sensor and the
temperature display. Therefore, the temperature rotary knob has no scribed scale.
Setting the bathing temperature
1. Turn the rotary knob for the bathing temperature D all the way to the right until the stop.
2. Observe the temperature display in the cabin.
3. Has the desired bathing temperature been reached? Turn the temperature rotary knob D slowly to
the left.
A soft click in the control system can be heard. Leave the rotary knob temperature D in this
position.
After approx. 30 minutes: Climate in cabin is obtained.
Adjust bathing temperature
1. Adjust rotary knob temperature D to the desired bathing temperature.
2. Mark the bathing temperature that suits you most.
6.2. Setting the exhaust air flap for cabin ventilation (option)
Ventilation: Heating mode
Exhaust air flap, level 1
With this position, there is only a low air flow.
Ventilation: Sauna mode
Exhaust air flap, level 4
Bathing operation with maximum number of sauna
users. With this position, there is a maximum air flow.
1
It is better to obtain a larger air flow volume for the
sauna climate. Intermediate stages can be selected in
accordance with the number of sauna users.
