Product Description and Control Panel
Item 10029294
1 Front Lid 6 Division Plate 11 Icefull Sensor Plate
2 Viewing Window 7 Silicon Stopper 12 Water Level Buoy
3 Evaporator Bracket 8 Control Panel 13 Fan Cover
4 Middle Frame(Water Tank) 9 Back Top Cover 14 Plug
5 Ice Basket 10 Evaporator 15 Back Cover
Item 10029295
1 Front Lid 7 Control Panel 13 Fan Cover
2 Water Level Bouy 8 Back Top Cover 14 Plug
3 Water Pump 9 Viewing Window 15 Back Cover
4 Water Receiver 10 Evaporator 16 Drain Pipe
5 Middle Frame 11 Icefull Sensor Plate 17 Water Inlet Hole
6 Front Shell 12 Handle
