23
Für das Model 10031910
1. The cooker hood should be placed at a distance of
65-75cm (26-30inch) from the cooking surface for
the best effect. See Pic 1.
2. Install the hanging screw on a suitable place once
the installation height is fixed, drill 2 holes and in-
sert the Wall plug.put 2pcs screws(ST4*30mm)into
wall plug, and keep it in line. See Pic 2.
3. Hang the cooker hood on the screws ,
4. Use 2 screws (S4*30mm) to fix the safety locks in
the cooker hood on the wall. See Pic 3
Bild 1
Bild 3
Bild 2
