HOW TO INSTALL THE WINDOW SEAL
Installing the window sealing is easy. You can attach it to a tilted window or to a laterally
opened window. Our demonstration is performed on a laterally opened window. It is
especially suitable for low positions of the exhaust pipe.
The velcro tape must be attached on three sides. Leave out the side with the window
being connected to the frame. Clean the frame and dry it rst, so that the tape sticks.
1 2 3
Attach the velcro tape on
the left, on the top and on
the bottom of the window
frame.
We recommend that you
cut the tape into strips for
each window side rst.
Now attach the velcro
tape to the inner window
sides.
Stick the window sealing
to the velcro strips on
the window frame rst
(starting with the top), then
on the velcro strips on the
window.
Push the exhaust air tube
of the air conditioner
through the hole, which
can be adjusted in height
and size.
