Klein Tools 93PLL User Manual

6
7
ENGLISH
NOTE:
The Pendulum Slider Switch
10
Indicator
4
pendulum to function appropriately.
OPERATING INSTRUCTIONS
MAGNETIC MOUNTING BRACKET
14
A magnetic mounting bracket is included with the product. The instrument can be
mounted on the bracket via its 1/4" threaded screw
15
. The bracket may be magnetically
attached to any ferrous structure such as steel studs, ducts, structural beams, and steel
doors. The bracket also feature a keyhole for mounting the instrument using a screw or
nail to non-ferrous structures. Once mounted to a structure via the mounting bracket, the
instrument can be rotated on the bracket through 360° to direct the laser beams.
X-Plane Laser Line
Instrument Tilted Excessively
RECHARGING BATTERY
When the Red LED on the Battery Level Indicator blinks, the battery needs to be recharged:
Charging Battery via 93PLL USB-C Port:
1. Connect supplied charging cable’s
13
USB-C connection to the USB-C port
6
of
the 93PLL.
2. Connect the charging cable’s USB-A port to a charging source (5V DC, Min 2.0A, not
included).
3. The Battery Level Indicator
5
will illuminate to indicate charging status (TABLE 1).
4. A full charge can take up to 8.5 hours, depending on the charger’s output. Charge
completely before using.
Charging Battery via Battery Pack
USB-C Port:
1. Ensure 93PLL is turned off by
locking the Power/Pendulum
Switch
10
.
2. Loosen screw from the Battery
Door
12
and remove battery.
3. Connect the supplied charging
cable’s
13
USB-C connection to
battery's Charge-In Port
16
.
4. Connect the charging cable’s
USB-A port to a charging source
(5.0V, min. 2.0A, not included).
5. Battery Charge Indicator LED
17
will blink red while charging,
and turn solid green when fully
charged. When fully charged,
disconnect cable from battery
and reinstall battery in 93PLL.
6. Close the battery door and secure with screw. Do not over-tighten.
TABLE 1
Not
Illuminated
Green Yellow Red Blinking
LED Status % Charged
Solid green
Solid green
Solid yellow
Solid red
100% charged
Blinking green
Solid green
Solid yellow
Solid red
75% to 99% charged
Blinking green
Blinking green
Solid yellow
Solid red
50% to 74% charged
Blinking green
Blinking green
Blinking yellow
Solid red
25% to 49% charged
Blinking green
Blinking green
Blinking yellow
Blinking red
0% to 24% charged
