GENERAL SPECIFICATIONS
The Klein Tools VDV500-063 Toner-Pro is a professional-series tone
generator for wire identification, wire tracing and wire pair identification.
It features several tone frequencies and strong power output for tracing
wires.
•
Operating Altitude: 6562 ft. (2000 m) maximum
•
Relative Humidity: 10% – 90% non-condensing
•
Operating Temp: 14° to 122°F (-10° to 50°C)
•
Storage Temp: -4° to 140°F (-20° to 60°C)
•
Dimensions: 2.5" x 5" x 1" (64 x 127 x 25 mm)
•
Weight: 7.4 oz. (210 g) including batteries
•
Battery Type: 4 x 1.5V AAA Alkaline
•
Battery Life: Active: 120 hours
Standby/Storage: 3 years
•
Auto-Power Off: After 60 minutes of inactivity
•
Tones: Constant: 800Hz, 1000Hz, 1500Hz
Alternating: 800Hz/1000Hz, 1000Hz/1500Hz
•
Tone Power: 8dBm
•
Continuity Indication: Less than 10kΩ
•
Voltage Protection: Test Mode: 60V
Tone Mode:
20V through external 600Ω
Specifications subject to change.
T16
T12
T15
FEATURE DETAILS
