12 Manual CPM 374
Confirm the selection and exit SETUP by pressing «A». Mount the selected part (Mk11 or Plate)
on the system. The result is displayed in Volts for the selected part.
5.3.2. Zero Adjust
If you press button «B» for NO in 5.3 Settings the device asks for a zero adjust:
Press «A» for a zero adjust or «B» to leave the menu. After pressing «A» the prompts whether
MK11 or Plate is installed:
For a proper zero adjust the measuring head has to be grounded:
Ground the measuring head and confirm that by pressing button «A». Afterwards the zero adjust
is performed and the device returns:
Important: During the zero adjust external voltage must not be connected to the device or the
measuring head, because otherwise no proper zero adjust can be performed.
To perform a zero adjust without MK11 please mount the protective cap and confirm this as
grounded MK11 in the menu.
By mounted Plate it is asked if the plate is free ? Then the plate is grounded internal !
PLEASE WAIT !
