13 Electrostatic Field Meter Mode
6. Electrostatic Field Meter Mode
For operation in electrostatic field meter mode the upper plate has to be removed. Νο
ΝοΝο
Νο measuring
head may be installed.
6.1. Metering an Electrostatic Field
Only static (DC) fields can be measured with the integrated electrostatic field meter
1
. The display
directly shows the electric field strength in (kilo)Volt/meter:
6.2. Adjust Range
By pressing button «A» the selected range can be changed. You can choose between the follow-
ing options:
6.3. Zero Adjust
The provided protective cap has to be mounted on the modulator system to perform a zero ad-
just. After pressing «A» and «B» simultaneously for about 1s the device asks whether a zero
adjust should be performed:
Quit by pressing button «B» or press «A» YES to advance. The device asks to put on the protec-
tive cap:
Put the protective cap on the modulator system and press «A» to perform the zero adjust. Press-
ing button «B» closes the menu.
7. Further Messages
In case of a damaged electrostatic field meter the device displays:
1
Frequenz f<1Hz
PUT ON COVER ?
