CONNECTING THE FHT/S-CONTROL:
During installation/de-installation of the thermostat the electricity should always be turned off at the mains. Installation
must be carried out by a qualified electrician in accordance with the IEE Regulations. The FHT-Control thermostat is
equipped with an intelligent guide function that leads the user through the programme and is extremely user friendly.
Still carefully read this manual nevertheless and keep it with your other guarantees.
INSTRUCTIONS FOR THE ELECTRICIAN:
Check that the electricity is turned off. Remove the display housing by inserting a blunt, suitable instrument, e.g. a coin or
point of a ballpoint carefully into the square hole at the top of the thermostat and exerting a light pressure. Both the
display housing and the cover plate can then be removed.
WIRING DIAGRAM:
Installation is done as follows:
- 1, 4 and 5 (earth) are used for the connection wires from the heating cable.
- 2 (Neutral), 3 (Live) and 6 (Earth) are for the power supply.
- 7 and 8 (earth) are for connecting the sensor.
INSTALLATION:
Position the thermostat and mount and secure it in the back box with two screws. Replace the cover plate and position the
display housing back in place and softly press it into position. When the power is turned on the first question will be dis-
played on the start up menu. Follow the start up menu carefully.
