Klipsch R-10B Reference

ONOFF
Power
DC IN
Optical
R
L
Headphone
71
2
3
5 6
Soundbar
TV
4
3.5mm TO DUAL RCA ANALOG CONNECTION (IF TV HAS NO HEADPHONE OUT SEE NEXT PAGE)
CONNEXION ANALOGIQUE 3,5 MM VERS DOUBLE FICHE RCA • CONEXIÓN ANALÓGICA RCA DE 3.5 MM A DOS RCA • 3,5 MM ZU DOPPEL-CINCH-ANALOGKABEL • CONNESSIONE ANALOGICA CON JACK DA 3,5 MM A DOPPIO JACK RCA CONEXÃO ANALÓGICA DE 3,5 MM • PARA RCA
DUPLO • 55ሎට:+)଍ୌৼࢫ
CABLE NOT INCLUDED

Klipsch R-10B Specifications

General

Frequency Response	27Hz - 20kHz
Bluetooth	Yes
Channels	2.1
Max Acoustic Output	110 dB
Enclosure Type	Bass-reflex via rear-firing port
Finish	Black
Inputs	Optical
Total System Power	250W
Tweeter	2 x .75” (19mm) soft dome tweeters mated to dual 90° x 90° Tractrix horns
