Klipsch R-51PM User Manual

19
LED
USB
PHONO OPT
AUX
SUBSUB
SUB
LED
USB
PHONO OPT
AUX
SUBSUB
SUB
LED
USB
PHONO OPT
AUX
SUBSUB
SUB
Release
Libération
Lanzamiento
Freisetzung
Liberare
Lançamento
发布
Press and Hold
Appuyer et Maintenir
Presione y mantenga
Drücken und halten
Tieni premuto
Pressione e segure
按下并保持
DISABLE AUTO-STANDBY
DÉSACTIVER LA VEILLE AUTOMATIQUE • DESHABILITAR AUTO-STANDBY • DEAKTIVIEREN SIE DEN AUTOMATISCHEN STANDBY-MODUS • DISABILITA L’AUTO-STANDBY • DESATIVAR A ESPERA AUTOMÁTICA • 禁用自动待机 •
4
2



LED Turns Purple
LED Violet
LED Morado
LED Lila
LED Viola
LED Roxo
LED 紫色
6
LED
Select Source to Phono, Analog, Digital or USB
Sélectionner la source Phono, auxiliaire, Optique ou USB
Seleccionar tocadiscos, auxiliar, Óptica o bien USB
Quellenwahl auf Phone, AUX, Optische oder USB
Selezionare il segnale per phono, ausiliaria, Ottica oppure USB
Selecione a fonte para o fono, auxiliar, Ótica ou USB
选择源至唱机,辅,数字或USB
USBDIGITALANALOGPHONO
1
Press
Appuyer
Oprima
drücken
Premere
Pressionar
按

3
Press
Appuyer
Oprima
drücken
Premere
Pressionar
按

7
Press
Appuyer
Oprima
drücken
Premere
Pressionar
按

5

Klipsch R-51PM Specifications

General

Type	Powered Monitor
Low Frequency Driver	5.25" Spun-Copper IMG Woofer
Weight	10.6 lbs (4.8 kg)
Frequency Response	68Hz - 21kHz
High Frequency Driver	1" Aluminum LTS tweeter
Inputs	Bluetooth, Optical, Analog , USB
Outputs	Single RCA line level output for connection to subwoofer
Dimensions	13.3" x 7" x 8.5"
Voltage	100V-240V
Crossover Frequency	1, 660 Hz
