LR
LINE IN
RL/LFE
LINE IN
RL/LFE
FIGURE 2
SPL-100 AND SPL-120 SUBWOOFER HOOK UP
PRE • OUT LFE OUTPUT
Left and Right pre-outs on Processor/Pre-Amp/Receiver connected to
Left and Right line inputs on subwoofer amplifier
LFE Output on Processor/Pre-Amp/Receiver connected to LFE input on
subwoofer amplifier
OR
Processor/
Pre-Amp/Receiver
Processor/
Pre-Amp/Receiver
