1. Hold the latch in front of the door
hole so that the latch is ush with
the door edge.
2. Press the square-shaped hole
and pull the latch to set the latch
backset to 60mm(2-3/8") or
70mm(2-3/4") to t your door hole.
3. Make sure the square-shaped hole
places the horizontal position.
1. Insert the latch into the door
hole,and tighten Screw A to x
the latch.
2. Install strike box and strike
plate with screw A into the
door frame.
Install Latch and Strike
4
