PARTS LIST
PART DESCRIPTION KLM PART NUMBER QUANTITY
Swaged Tube, 1-1/2" O.D. x 64" 2
Straight Tube, 1-1/2" O.D. x 31" 1
Dipole Element, 3/8" O.D. x 72" 2
Element, 3/16" O.D. x 40-5/8" 2
Element, 3/16" O.D. x 35-5/8" 4
Element, 3/16" O.D. x 35-3/8" 6
Boom-to-Mast Plate, 4" x 6" x 1/8" 1
Phasing Coupling, CS-14C 1
Harness
Coax Balun 2
Assembly Manual 84041 1
Hardware Bag #1 1
U-Bolts and Cradles, 1-1/2" 28401 4
Hardware Bag #2 1
Screws, 6-32 x 1-3/4" 28008 1
Nut, 6-32 28201 1
Lock washer, #6 28351 1
Screws, 8-32 x 1" 28031 4
Screws, 8-32 x 1-3/4" 28016 4
Screws, 8-32 x 3" 28020 2
Nuts, 8-32 28202 18
Flat washers, #8 28302 8
Lock washers, #8 28352 18
Nuts, 5/16-18 28206 8
Lock washers, 5/16" 28356 8
Large Nylon Ties 66119 8
Type II Insulator, 3/8" x 1-1/2" 66114 2
Push nuts, 3/16" 28218 28
Peanuts 66117 4
Boom Plugs, 1-1/2" 66117 2
Button Insulator 66125 24
