SPECIFICATIONS:
Coverage: 143-150 MHz (no retuning)
Polarization: Circular
Gain : 11 dBdC
Elipticity: 3 dB max.
VSWR: Better than 1.5:1
Beamwidth: 48 degrees
Balun(s): 4:1 coax (2) 2KW PEP
Stacking Distance, H or V: 8-10'
Number of Elements: 14: 7H, 7V
Feed Impedance: 50 ohms, unbalanced
Boom Length/Diameter: 12'9"/1-1/2" O.D.
Mounting/Mast: Center/2" Mast
Weight: 7-1/2 Ibs.
Windload: 1.2 sq. ft.
Switcher, Power Rating: 600W PEP
ANTENNA ASSEMBLY
BEFORE YOU BEGIN
1. Select an assembly area large enough to comfortably accommodate overall
antenna dimensions. A shallow box is handy for holding and sorting the smaller
hardware, as is a marking pen for identifying components.
2. Some simple tools are required: a tape measure, screwdriver, and a set of
spintite, socket, or end wrenches. Common nut sizes are:
5/16" = 6-32 hardware 7/16" = 1/4-20 hardware
11/32" = 8-32 hardware 1/2" = 5/16-18 hardware
To avoid damage to antenna components, be aware that most hardware needs
only be moderately hand-tightened with screwdriver or spintite to be secure. When
using tools with mechanical leverage, such as socket or end wrenches, care must be
taken not to over-torque nuts and damage components.
3. Thoroughly unpack shipping box and check components and hardware against
the Parts List. If there is a difference, look for a "Factory Update/Change" sheet
accompanying the assembly instructions prior to contacting your KLM dealer or the
factory.
