16
OPERATING INSTRUCTIONS
10. Bevel Cutting
To make the best possible cut:
a. Adjust the angle of cut to any desired setting
between 0° and 50°.
b. Align the cutting line with the 45° blade-guide
notch (M) on the base when making 45° bevel
cuts.
c. Make a trial cut in scrap material along a
guideline to determine the amount to offset the
guideline on the cutting material.
WARNING
• Attempting a bevel cut without having the bevel-
locking knob securely locked in place can result in serious injury.
d. Hold the saw rmly with both hands, as shown.
e. Rest the front edge of the base shoe (V) on the workpiece without touching the blade to
the workpiece.
f. Depress the trigger switch (A) to start the saw.
g. Allow the blade (J) to reach full speed, then guide the saw into the workpiece and make
the cut.
h. Release the trigger switch and allow the blade to come to a complete stop.
i. Lift the saw from the workpiece.
NOTICE: Do not bind the blade in the cut.
10
M
