OPERATING INSTRUCTIONS
5. Speed Selector
The impact driver has a speed selector (F) located on
the base to select among three different variable-speed
ranges (refer to specications section).
1: The impact driver provides lowest speed and torque.
2: The impact driver provides medium speed and torque.
3: The impact driver provides maximum speed and
torque.
NOTICE: Do not change speed range while the tool
is running. The speed range will not change until you
release the variable-speed trigger switch.
6. Finish Mode
The nish mode permits better control of the impact
driving action and is useful as the head of the fastener
approaches the level of the workpiece. In nish mode,
each successive depression of the variable-speed trigger
switch (D) will result in a very short impacting burst. The
nish button (E) is located on the base of the tool.
a. To engage the nish mode, ensure a battery is
correctly attached to the tool, depress and release
the variable-speed trigger switch to turn on the tool,
then press the nish button. The green light on the
nish button will illuminate to indicate that the nish
mode is activated.
b. The nish mode can be turned on and off for
approximately 15 minutes after the last variable-
speed trigger release.
c. If more than 15 minutes have passed, repeat the process described above to engage the nish
mode.
6
E
5
F
