PACKAGE CONTENTS
B
M
N O P Q
A
C
D
E
G
F
H
K
J
L
I
PART DESCRIPTION PART DESCRIPTION
A Switch-lock button J Base plate
B Variable-speed trigger switch K Base-plate protecting cover
C LED work light (located in housing) L Bevel lever
D Blade guard M Dust-blowing lever
E Blade clamp N Edge guide
F Edge-guide slot O Locking screw (2)
G Blade roller guide P Hexagon wrench
H Blade-release lever Q Blade (2)
I Orbital-function lever
WARNING
• Remove the tool from the package and examine it carefully. Do not discard the carton or any
packaging material until all parts have been examined.
• If any part of the tool is missing or damaged, do not attach the battery pack or use the tool
until the part has been repaired or replaced. Failure to heed this warning could result in
serious injury.
