17
Chain tension
• Stop the motor and remove the battery before
setting the chain tension. Turn the bar cover knob
counterclockwise to loosen the bar cover but do not
remove the bar cover. Turn the chain tensioning screw
clockwise to tension chain. Turn the guide bar knob
clockwise to tighten. Refer to the Replacing the bar
and chain section for additional information.
Note: A cold chain is correctly tensioned when there is
no slack on the underside of the guide bar, the chain is
snug, but it can be turned by hand without binding.
•
drive links hang out of the bar groove.
• During normal operation, the temperature of the chain
will increase. The drive links of a correctly tensioned
warm chain will hang approximately 1/16 in. (1.3 mm)
out of the bar groove.
Note: New chain tends to stretch; check chain tension
frequently.
CARE AND MAINTENANCE
Chain tensioned while warm may be too tight upon
cooling. Check the “cold tension” before next use.
CAUTION
Replacing the bar and chain
WARNING
To avoid possible serious injury, stop the motor and
remove the battery from the pole saw before replacing the
bar, chain, or performing any maintenance operation.
APPROX 1/16 in. (1.3 mm)
Flats
