Kobalt KSB 1040B-03 User Manual

20
CARE AND MAINTENANCE
12. Replacing the Scraper Bar
WARNING
Make sure to turn off the snow blower by releasing
the bail switch and remove the battery pack(s)
before performing any maintenance task on your
snow blower.
a. The scraper bar (S) is located at the bottom of
the snow blower beneath the auger (Fig. 12a).
b. Turn the snow blower on its side (Fig. 12b).
c. To reduce the risk of injury, wear gloves. Use
a 5/16” (8mm) socket wrench (not included) to
remove the 5 nuts (Fig. 12c). Detach the worn
scraper bar from the snow blower.
d. Attach the new scraper bar to the snow blower
with the shiny surface facing the inside of the
deck. Align the mounting holes in the scraper
bar with the holes in the deck. Insert the 5 bolts
into the mounting holes from the inside, shiny
surface of the scraper bar (Fig. 12c).
12a
S
12b
Nut
Scraper Bar
12c
Shiny
surface
Washer
Nut
Bolt

Kobalt KSB 1040B-03 Specifications

General

Clearing Width	20 inches
Battery Voltage	40V
Battery Type	Lithium-Ion
Corded/Cordless	Cordless
Engine Type	Brushless Motor
Power Source	Battery
Warranty	5-year limited
Intake Height	12 inches
Start Type	Push-button
Max Runtime	Up to 45 minutes
Charging Time	60 min
