14
4
3
INSTALLING THE HOLD-DOWN CLAMP (FIG. 3)
NOTE: There are two mounting holes for the
hold-down clamp. These are located just behind
the fence on the left and right side of the base.
● Loosen the lock knob behind the fence.
● Place the hold-down clamp (B) in the desired
mounting hole.
● Tighten the lock knob to hold the hold-down
clamp.
BLADE WRENCH (FIG. 4)
For convenient storage and prevention of loss,
there is a holder in the rear of the right side
fence for storing the blade wrench (D) when not
in use.
B
Lock
knob
Mounting holes
D
