REMOVING AND INSTALLING THE TABLE
INSERT (FIG. 7)
NOTE: The miter saw comes with the table
insert already installed. These instructions are
for replacing or adjusting the insert.
To avoid injury:
● Always unplug the saw to avoid accidental
starting. Remove all small pieces of material
from the table cavity before performing any
cuts. The table insert may be removed for
this purpose, but always reattach the table
insert prior to performing a cutting operation.
● Do not start the sliding compound miter
saw without checking for interference
between the blade and table insert.
Damage could result to the blade, table
insert or turntable if blade strike occurs
during the cutting operation.
● To remove, loosen and remove the six
screws (1) on the table insert (2) with the
cross end of the provided blade wrench and
remove the insert.
● To install, reposition the table insert, install
the six screws and tighten.
● Check for blade clearance by moving the
slide carriage through the full motion of the
blade in the table slot.
MOUNTING THE MITER SAW (FIG. 8, 9, 10)
To avoid injury from unexpected saw movement:
● Disconnect the power cord from the outlet
and lock the cutting head in the lower
position using the stop latch.
● Lock the slide carriage in place by tightening
the slide carriage lock knob.
● To avoid back injury, lift the saw by using the
hand holds for transportation. Bend with your
knees, not your back.
● Never carry the miter saw by the power cord
or by the switch handle. Carrying the tool by
the power cord could cause damage to the
insulation or the wire connections resulting
in electric shock or re.
● To avoid injury from ying debris, do not
allow visitors to stand near the saw during
any cutting operations.
WARNING
2
1
WARNING
8
10
10
10 10
