CARE AND MAINTENANCE
16
WARNING
Risk of Explosion. Disconnect,
tag and lock out power source,
then release all pressure from the
system before attempting to install,
service, relocate or perform any
maintenance.
1. Disconnect, tag and lock out power source; clean
debris from motor, flywheel, tank, air lines and pump
cooling fins.
2. Maintain proper oil level. Refer to Lubrication section
for details.
3. Change oil.
a. Allow compressor to run and warm up oil.
Disconnect, tag and lock out power source.
b. Position a pan under pump.
c. Remove oil drain plug (See Figure 1). Allow oil to
collect in pan.
d. Replace drain plug, fill pump to full level (See
Figure 1). See Lubrication section of this manual.
All repairs should be performed by an authorized service representative.
For efficient operation, perform the following maintenance.
2
NOTICE
Unit Care and Maintenance. Drain liquid from
tank daily.
4. Drain Tank. Disconnect, tag and lock out power
source; release pressure. Drain moisture from tank
by opening drain valve underneath tank or on side of
tank (See Figure 2).
5. Check air filter to be sure it is clean. Replace filter if
filter is dirty.
1
Oil Fill Plug
Oil Drain
Plug
