Kobalt TQ3126 User Manual

25
REPLACEMENT PARTS LIST
PART DESCRIPTION PART NUMBER QTY.
1 Air tank AR232401CG 1
2 Drain valve ST127700AV 1
3 Air compressor pump with flywheel TQ300000AV 1
4 5/16 inch - 18 x 1-1/2 inch Hex head bolt
k
4
5 5/16 inch - 18 Locknut
k
8
6 5/16 inch - 18 x 3/4 inch Hex head bolt
k
4
7 5/16 inch Washer
k
4
8 Electric motor MC019300AV 1
9 Motor pulley PU017000AV 1
10 Flywheel PU017100AV 1
11 Belt BT013100AV 1
12 Pipe nipple HF002401AV 1
13 Pressure gauge GA031900AV 1
14 Safety valve V-215109AV 1
15 Electric cord EC014800AV 1
16 Unloader tube ST117802AV 1
17 Straight push connect ST081301AV 1
18 Check valve CV223300AV 1
19 1/2 inch Compression sleeve ST032900AV 1
20 1/2 inch Compression nut ST033001AV 1
21 Discharge tube TQ901600AP 1
22 Front beltguard BG021600AV 1
23 10-24 Hex-flange nut ST116201AV 5
24 5/16 inch Washer ST011200AV 2
25 5/16 inch Self-tapping screw ST016500AV 4
26 Back beltguard BG021701AV 1
27 Pressure switch (with unloader valve) CW218800AV 1
28
Pressure switch unloader valve (
)
CW210001AV 1
29
Pressure switch cover (
)
CW217800AV 1
30 Flywheel Fastener Kit TQ901400AV 1
31 Capacitor - Start MC507018AV 1
32 Capacitor - Run MC506910AV 1
33 Easy Drain Assembly D-140501AV 1
34
Warning decal (
)
DK747600AV 1
Not shown
k
Standard hardware item
For replacement parts, call our customer service department at 1-888-3KOBALT (1-888-356-2258),
8:00 am - 8:00 pm, EST, Monday - Friday.
