REPLACEMENT PARTS LIST
PART DESCRIPTION PART NUMBER QTY.
1 Crankcase TQ010001AV 1
2 Oil Seal ST120000AV 1
3 Bearing Cap TQ010201AV 1
4 O-Ring
n
1
5 Hex Head Cap Screw M8 x 25 mm
k
2
6 Crankshaft and Bearing Assembly TQ900201AJ 1
7 Crankcase Gasket
n
2
8 Connecting Rod / Piston Assembly Kit TQ901500AV 4
9 Piston Ring Sets (two sets) VT911200AV 2
10 Wrist Pin Kit [includes retaining rings] TQ901800AV 4
11 Cylinder VT040915AV 2
12 Cylinder Gasket
n
2
13 Molded O-Ring
n
2
14 Valve Plate Kit VT470800AJ 2
15 Cylinder Head
s
2
16 Hex Head Cap Screw M8 x 150 mm
s
8
17 Flange Head Screw
s
4
18 Exhaust Tee Fitting TQ901100AV 1
19 Exhaust Elbow Fitting TQ901200AV 1
20 Exhaust Tube TQ901300AV 1
21 Breather VH901100AV 1
22 Oil Fill Plug VH900800AV 1
23 Air Filter with Element VH901700AV 2
24
Air Filter Element only (
)
VH901800AV 2
25 Sight Glass VH901000AV 1
26 Pipe Plug 1/4 inch NPT ST072915AV 1
27 Belt Guard Bracket TQ012000AV 1
28 Brass Washer ST070925AV 2
29 Connecting Rod TQ010901AJ 4
30 Piston with Rings Kit TQ901700AV 4
REPLACEMENT PARTS KITS
s
Cylinder Head and Fasteners Kit TQ900800AJ
n
Gasket Kit TQ901001AJ
Not shown
k
Standard hardware item
For replacement parts, call our customer service department at 1-888-3KOBALT (1-888-356-2258),
8:00 am - 8:00 pm, EST, Monday - Friday.
