4-62
ï¼»4. INSPECTION AND MAINTENANCEï¼½
4.16.6 CLEANING OR REPLACING RADIATOR CAP
HANDLING OF COOLANT AND CAP
Do not loosen or remove the reserve tank cap and the radiator cap when the coolant is under high pressure and
high temperature.
High temperature steam and coolant will spray and could cause burns.
• When opening the cap, wait until the coolant cools down, and then slowly turn and open the radiator cap.
• The antifreeze is poisonous, so prevent it from contacting with skin. If the antifreeze gets into your eyes or on
your skin, flush the eyes or skin with plenty of water, and seek medical attention.
Securely close the cap after opening it.
Inspection/cleaning Replacement
Every 250 hours If damaged, or every 1 year
1. Open the engine hood and hold it with the stay.
2. Loosen radiator cap (1) slowly. After checking that
the pressure is completely released, push the cap
down, loosen it further, and then remove it.
3. Check the following points of the cap. If foreign
materials are adhered, remove them and if any
damages are found, replace the parts.
A: Contact surface between negative pressure valve
(2) and gasket (5)
B: Both surfaces of pressure valve (3) and gasket
(5)
C: Both surfaces of external lid (4) and gasket (6)
4. Close cap (1) and close the engine hood.
Copyright©2020 Kobelco Construction Machinery Co.,Ltd. All rights reserved. [S2LP00004ZE03] [0701CsCshWbYs]
