27 KODAK CAROUSEL® Slide Projector
Troubleshooting
Slide fails to drop into projection
position
Tray base plate not properly indexed Align the index hole and index
notch.
Tray not properly positioned on
projector
Reposition tray on projector.
Slide mount warped or frayed at
corners slide.
Straighten mount or remount
slide.
Projector not level or tilted too high Set projector on a stand equal
with center of screen.
Uneven illumination on screen Projection lamp not fully seated Check lamp.
Condenser lens not installed or not
positioned properly in mount
Check condenser lens.
Slide mount not seated properly in
projector gate
Check slide position and slide-
mount condition.
Projector won't cycle to next slide Tray not properly positioned Reposition tray.
Slide or foreign object stuck in gate See "Clearing a Gate Jam" on
page 17.
PROBLEM CAUSE CORRECTION
