Kodak C520 - EXTENDER POSITIONING GUIDELINES; Recommended Location for Extender

Parent Unit Status Bar
18:30
2
1 2
3
VOX
9 10
23°C 58%
7 8
11
4 5 6
17
18 19
12
13
Page l 38
14
15
16
Parent Unit Status Bar
1. Wi-Fi Signal
2. Local Time (available
when the Camera(camera) is
connected to the Internet)
3. Device Number
4. Camera Battery Status
5. Parent Unit
6. Parent Unit Battery
Status
7. Temperature
15. Extender in Use
16. Extender in Use with
Home Mode
17. Device Number (Split
Screen Function)
18. Sound Indication (Split
Screen Function)
19. Sound Detection (Split
Screen Function)
8. Humidity
9. Talk Key (appears as you
press on the talk back key on
the parent unit)
10. Outdoor/Indoor mode
11. Voice Activation
Alert(vox)
12. Router Mode
13. Direct Mode
14. Home Mode
