Handling and Loading Paper
14 Kodak ESP 5 Printer User Guide
Loading Plain Paper
1 Pull the paper tray all the way out until the paper
guide flips up on the right side.
2 Slide the paper-width guide to its left-most
position.
3 Align the edges of a stack of paper.
4 Insert the stack of paper into the paper tray with
the print-side down.
5 For paper less than 8.5 inches wide, squeeze the
paper-width guide and slide it to the right until it
lightly touches the stack of paper.
6 Leave the aperp tray open when paper is loaded.
7 Pull the output tray extender all the way out.
8 Lift the small gray paper stop (at the near edge
of the output tray extender) until it is
perpendicular to the tray.
Loading 4 x 6 Photo Paper
You can load up to 30 sheets of 4 x 6 inche (101 x
150 mm) photo paper into the paper tray. Photo
paper must be loaded coated side facing down.
1 Remove all other paper from the paper tray.
2 Insert photo paper into the right side of the
paper tray print-side down, with the short edge
forward. Do not overload the paper tray.
3 Slide the paper forward until it stops.
4 Squeeze the paper-width guide and slide it to
the right until it touches the loaded paper.
5 Leave the paper tray open while the paper is
loaded.
