Kodiak Recirculating Chiller Technical Manual
Manual # 820-0109, Rev. Y, 07/08/10 - 8 - Check Lytron’s website www.Lytron.com
for the most current technical information.
PART NUMBER DESCRIPTION
RC006 G03 BB 1 MXXX
Basic
Model No.
Electrical
Configurations
Pump
Options
Controller
Configuration
Std.
Modification
RC006 - 825 Watts
RC009 – 1,050 Watts
RC011 – 1,650 Watts
RC022 – 2,400 Watts
RC030 – 3,450 Watts
RC045 – 5,900 Watts
Note:
Cooling capacity and
pump flows are rated
at 60Hz. For 50Hz
power capacity is
reduced by 17%.
G03 = 115V~/1ph/60Hz
H03 = 230V~/1ph/50Hz
J03 = 230V~/1ph/60Hz
AA* †= CP-15
Centrifugal Pump
BB (CB†) = 1.3 gpm
Positive Displacement
Pump
BC (CC†) = 1.8 gpm
Positive Displacement
Pump
BE (CE†) = 2.3 gpm
Positive Displacement
Pump
BG (CG†) = 4.3 gpm
Positive Displacement
Pump
DA* † = CP-25
Centrifugal Pump
EB* (FB†) = 1/4 Hp
Turbine Pump
EC* (FB†) = 1/6 Hp
Turbine Pump
Notes:
* Water filter and DI
cartridge not
recommended with
Centrifugal & Turbine
pumps.
† Indicates high
purity compatible
pump.
CONTROLLER PACKAGE #1
1. Alarm Mute
2. Audible Alarm
3. Auto-Restart
4. Calibration Offset
5. Deg °C / Deg °F Toggle
6. Digital Temperature
Display
7. Low Flow Shut-Off Fault
CONTROLLER PACKAGE #2:
1. Alarm Mute
2. Audible Alarm
3. Auto-Restart
4. Calibration Offset
5. Deg °C / Deg °F Toggle
6. Digital Pressure Sensing &
Display
7. Digital Temperature
Display
8. Fault Shut-Off (toggle
on/off)
9. Low Flow Shut-Off Fault
10. Low Level Fault
11. Low Temp / High Temp
Fault
12. Relay Contacts
CONTROLLER PACKAGE #3:
Same as "PKG 2" above
with the addition of RS-232
communications.
NOTE:
Refer to the product ID label on the on the rear of your chiller for the configuration you have purchased.
The table above refers to Lytron’s standard product offering for the Kodiak product line.
