Kodiak Recirculating Chiller Technical Manual
Manual # 820-0109, Rev. Y, 07/08/10 - 6 - Check Lytron’s website www.Lytron.com
for the most current technical information.
LABELS AND SILKSCREEN MARKING
EXTERNAL CONTACTS
.5 AMPS MAX
FILTER CARTRIDGE HAS
BEEN INSTALLED
RS-232
PUMP PRIMING VALVE
OPEN TO PRIME - CLOSE TO RUN
SUPPLY
RETURN
¾ The symbol on this label is intended to alert the user to
the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the
equipment.
¾ This symbol on this label cautions the user against the risk
of electrical shock. This label is mounted near of main
voltages of the system.
¾ External contacts have been installed.
¾ Lets customer know element has been installed.
¾ RS232 has been installed.
¾ Identifies the location of the pump priming valve.
¾ This silk-screen marking identifies the connection where
heated fluid is returned from the user’s machine.
¾ This silk-screen marking identifies the connection where
chilled fluid is supplied to the user’s machine.
¾ Positive earth (ground) terminal.
¾ The markings on this label certifies that the equipment has
been certified to the UL standard 61010A-1 and
CAN/CSA STD C22.2 No. 1010.1 standards.
¾ The symbol on this label identifies that the equipment has
been certified to regulations of the European Community.
