Kohler 10CCO

TP-5594 5/95 Scheduled Maintenance 3-11
2
1
ADV-5831-A
1. Coolant Outlet 2. Coolant Inlet
Figure 3-10. Coolant Fill and Coolant Drain Connections (Remote-Radiator Model)
1
2
ADV-5831-C
1. Initial Coolant Fill 2. Coolant Drain
Figure 3-11. Initial Coolant Fill and Coolant Drain Locations (Typical Inline-Radiator Model)
