Kohler 14RCAL

TP-7092 8/1838 Section 3 RDC2 Controller Operation
3.9 Overview Menu
Overview ---->
1.2 h
Active Alert
(if any)
tp6804
Genset Status
Standby
Voltage: 240V
Freq: 60.0Hz
Engine: 72F
Oil Pressure: OK
Battery
12.0V
Engine Runtime:
24.5 h
Date: 02DEC2011
Time: HR:MNpm
Next Exercise:
09:00p 09Dec2011
Next Maintenance:
150 h or Mar2012
SW Version:
4.07
<---- Return
Note: Actual settings may vary.
Figure 3-10 Overview Menu
3.10 Engine Metering Menu
The engine metering menu displays engine status
information as shown in Figure 3-11. This menu
displays status information only. No settings can be
changed from this menu.
tp6810
Eng Speed:
3600 RPM
Battery:
12.0 V
<---- Return
Engine ---->
Metering
Oil Pressure:
Switch: O K
Oil Temp:
72.0 F
Note: Actual settings may vary.
Figure 3-11 Engine Metering Menu
