TP-7092 8/18 49Section 3 RDC2 Controller Operation
3.18.4 Remote Devices Submenu
Check the status of remote devices communicating
through RBUS. Device types can include:
D Model RXT ATS
D Programmable Interface Module (PIM)
D Load shed kit or combined interface/load
management board on a Model RXT transfer switch
D PowerSyncr Automatic Paralleling Module (APM)
The serial number for the RBUS module is shown on the
circuit board inside the module enclosure.
tp6804
Module Status:
Connected
Firmware Ver.:
4.07
Module ID:
12
S/N: XXXXXXXXX
<<*DeviceType*>>
R e t u r n -- -- >
S/N: XXXXXXXXX
<<*DeviceType*>>
Comm. Errors:
12345
Comm. Timeouts:
12345
(Dis)Connected:
MM/DD/YY 12:12
<---- Return
Connected: Displays the date and time that the
device was connected.
Disconnected: Displays the last date and time of
successful communication.
R e m o t e -- -- >
Devices
From Figure 3-22:
Figure 3-23 Remote Devices Submenu
To Next Page
