Kohler 14RESA

TP-6805 8/15114 Section 6 Component Testing and Adjustment
7
6
1. Fuel block (used on 14 kW models before June 26, 2014)
2. Regulator
3. Fuel solenoid valve
4. Fuel inlet, 1/2 in. NPT female
5. Ignition timing leads
6. Fuel orifice location (see Figure 6-37)
7. LPG fuel orifice is tied here for shipping
8. Regulator vent tubes, used on 20RESA(L) and 20RESC(L)
after June 26, 2014
2
1
4
Ignition Timing Lead
Connection,
14 kW models
3
5
8
8
14kW Models before June 26, 2014
Figure 6-26 Fuel System
