TP-5592 7/96 Installation 6-7
ADV-5853-A
1
2
3
1. Fuel Return Connection
2. Fuel Feed Pump
3. Inlet Connection
Figure 6-6. Fuel Feed Pump (Inlet Connection) and Fuel Return Connection (Typical)
